Details
Product introduction
LISTRONG-Straight line steel wire drawing machine
The straight line wire drawing machine has international advanced technical index and performance.
It owns many inventive patents and practical new type patent,such as medium capstan cooling structure,die box tuning device,lubrication supply device,wire pressing device,wheel pressing device,straightening deivice and etc.
Technical parameters
Model: LISTRONG- Straight line steel wire drawing machine
|
Machine Type |
LZ560 |
LZ600 |
LZ800 |
LZ900 |
LZ1000 |
LZ1200 |
LZ1400 |
|
|
Capstan dia.(mm) |
560 |
600 |
800 |
900 |
1000 |
1200 |
1400 |
|
|
Die number |
2-14 |
2-12 |
2-10 |
2-10 |
2-9 |
2-9 |
2-6 |
|
|
Motor power(kw) |
22-45 |
30-45 |
45-75 |
75-132 |
90-132 |
90-160 |
110-200 |
|
|
Max.inlet(mm) |
Low carbon |
7.0 |
8.0 |
12 |
16 |
18 |
20 |
25 |
|
High carbon |
6.5 |
7.0 |
10 |
13 |
13 |
16 |
18 |
|
|
Min. outlet dia.(mm) |
1.4 |
1.6 |
2.6 |
3.0 |
3.2 |
4.0 |
4.5 |
|
|
Max. drawing speed(m/s) |
20-15 |
18-12 |
16-8 |
15-7 |
14-6 |
12-6 |
8-5 |
|
|
Machine Type |
LZ200 |
LZ250 |
LZ300 |
LZ350 |
LZ400 |
LZ450 |
|
|
Capstan dia.(mm) |
200 |
250 |
800 |
900 |
1000 |
1200 |
|
|
Die number |
2-16 |
2-16 |
2-16 |
2-14 |
2-14 |
2-14 |
|
|
Motor power(kw) |
5.5 |
7.5 |
7.5 |
11 |
15 |
22 |
|
|
Max.inlet(mm) |
Low carbon |
2.5 |
3.0 |
3.5 |
4.0 |
4.5 |
5.5 |
|
High carbon |
2.2 |
2.6 |
2.8 |
3.5 |
4.0 |
5.0 |
|
|
Min. outlet dia.(mm) |
0.25 |
0.4 |
0.5 |
0.6 |
0.75 |
0.8 |
|
|
Max. drawing speed(m/s) |
24 |
24 |
24 |
22 |
22 |
20 |
|
Packing & Delivery
Packaging details: Steel pallet.
Delivery Time: within 50 working days after confirming the order of the wire drawing machine.
