1
/
1
Rod breakdown machine with double spooler
Inlet: φ8mm/max
Outlet :φ1.38mm-φ3.8mm
Max. speed:1800mpm
零售价
0.0
元
市场价
0.0
元
数量
-
+
库存:
0
Details
Product introduction
LISTRONG-450/13D copper rod breakdown drawing machine
The copper rod breakdown drawing machine is one of the most important facilities in the plant. It is the evaluation point of the revenue of the cable factory. LISTRONG-450/13D copper rod breakdown drawing machine is suitable for inlet dia. 8mm/max, outlet dia. 1.38-3.8mm. It has a compact structure, wire straightness easy to adjust, good stability and many other advantages.
Application: Copper rod breakdown from inlet dia. 8mm/max to outlet dia. 1.38-3.8mm.
Main components of machine:
|
Serial No. |
Item Name |
Qtty. |
|
1 |
Pay-off stand |
1 set |
|
2 |
450/13D Main drawing machine |
1 set |
|
3 |
Tension controller |
1 set |
|
4 |
Double spooler |
1 set |
|
5 |
Electrical cabinet |
1 set |
|
6 |
Pointing machine |
1 set |
|
7 |
Spare parts |
1 set |
Technical parameters
Model: LISTRONG-450/13D copper rod breakdown drawing machine
|
Serial No. |
Item |
Description |
|
1 |
Inlet dia. |
φ8mm |
|
2 |
Outlet dia. |
φ1.38-φ3.8mm |
|
3 |
Max. drawing times |
13 |
|
4 |
Max. speed |
900mpm |
|
5 |
Dia. Of fixed-speed capstan |
φ450mm |
|
6 |
Lubricating and cooling mode |
Spraying and semi-soaking |
|
7 |
Mode of transmission |
Precision gear drive |
|
8 |
Material of gear |
Carburization surface quenching |
|
9 |
Material of shaft |
Steel heat treatment |
|
10 |
Bearing |
LYC |
|
11 |
Drawing capstan |
Surface W carbide treatment |
|
12 |
Motor of drawing |
185kw |
|
13 |
Motor of take-up |
15kw*2 |
|
14 |
Weight of machine |
11000kg |
|
15 |
Overall dimension |
7500*1710*1360mm |
FAQ
Q： Is the Listrong-450/13D copper rod breakdown drawing machine with continuous annealer?
A： No. This copper rod breakdown drawing machine is without annealer, but online annealer is optional to equip with the machine, please refer to the details of Listrong-450/13DT copper rod breakdown drawing machine with annealer or contact us for more details.
Q： What about the lead time of the Listrong-450/13D copper rod breakdown drawing machine?
A： Within 60 working days after confirmation the order.
Q： Who will be responsible for the delivery?
A： The Listrong-450/13D copper rod breakdown drawing machine is usually delivered by sea, under CIF term, we will be responsible for the delivery and insurance to the destination port instructed by buyer. If under FOB term, the buyer shall arrange for the shipment and insurance, we will be responsible for deliver the machine to the port of loading.
Packing & Delivery
Packaging details: wooden box, PE film, wooden/steel pallet.
Delivery Time: within 60 working days after confirming the order of the copper rod breakdown drawing machine.
